,QVWDOODWLRQ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
6-2 A5E00105492-03
$FFHVVRULHVLQFOXGHG
Installation accessories are included with the module package. The appendix
contains a list of accessories and spare parts together with the corresponding
order numbers.
Table 6-1 Module accessories
0RGXOH $FFHVVRULHVLQFOXGHG 'HVFULSWLRQ
1 x Slot number label For assigning slot numbers CPU
Inscription labels for the MPI address and
Firmware Version (all CPUs)
for labeling of integrated
inputs and outputs (CPU
31xC only)
Tip: Templates for labeling
strips are available on the
Internet at
http://www.ad.siemens.de/cs
info under article ID
11978022.
1 bus connector For electrical interconnection
of modules
Signal module (SM)
Function Module (FM)
1 labeling strip for labeling module I/O
Tip: Templates for labeling
strips are available on the
Internet at
http://www.ad.siemens.de/cs
info under article ID 406745.
1 bus connector For electrical interconnection
of modules
Communication module (CP)
1 inscription label
(only CP 342-2)
for labeling the connection to
the PLC interface
Tip: Templates for labeling
strips are available on the
Internet at
http://www.ad.siemens.de/cs
info under article ID 406745.
Interface module (IM) 1 x Slot number label (only
IM 361 and IM 365)
For assigning slot numbers
on racks 1 to 3
