Installing and Starting the Ethernet CP with STEP 7
52
SIMATIC NET NCM S7 for Industrial Ethernet
C79000-G8976-C129–06
2.2.3 Displaying the Network Attachments of a Station
Procedure
You can easily get an overview of the network attachment configurations of a
SIMATIC station in one of the following ways:
S A graphic overview in NetPro;
S An overview in table form in the Properties dialog of the station
Graphic Overview in NetPro
The NetPro view provides you with a good overview of the networked stations:
Follow the steps below:
1. Double-click one of the network objects, for example Ethernet in your project in
the SIMATIC Manager.
Figure 2-3 NetPro View of a Subnet of the Type Industrial Ethernet
