Siemens NCM S7 User Manual

Configuring Communication Connections
84
SIMATIC NET NCM S7 for Industrial Ethernet
C79000-G8976-C129–06
4.1 Procedure
Steps
The following steps are necessary to operate connections on the SIMATIC S7 PLC
with the Ethernet CP:
Program the
SEND/RECEIVE interface in
the user program.
(Refer to Section 3.2 and the
detailed FC description in
Chapter 5).
Programming
Create new
connections
If necessary,
configure “Other
Station” for
connections using the
appropriate tool.
Download connection configurations
to the CP
Configure connection
properties.
Configuring
necessary steps
optional steps
Figure 4-1 Operating Connections with the Ethernet CP
