SIMATIC NET NCM S7 for Industrial Ethernet
C79000-G8976-C129–06
SEND/RECEIVE Interface in the User
Program
This chapter explains the following:
S How to send and receive data.
S Which data areas can be used on the S7 CPU.
S How to program the SEND/RECEIVE interface in the user program.
You will find further information in the following sources:
S For programming and configuring nodes for connections (for example a
SIMATIC S5 PLC with the CP 1430 TCP, PC with CP 1413), please refer to the
appropriate manuals.
S The FCs for programming connections are described in Section 5.3.
S Configuring the Ethernet CP with NCM S7 is described in Chapter 4.
Sample programs:
Sample configurations and programs are available for the SEND/RECEIVE
interface described here:
S In the sample project PROJECT_ETHERNET that you can start immediately
after installing NCM S7; for a description, refer to the Primer /2/.
S On the Internet as downloadable sample projects; refer to the information in
Appendix C “Support and Training”.
The Quick Start CD that can be ordered separately is a
treasure-trove of sample programs and configurations.
You can order this directly on the Internet at:
http://www.ad.siemens.de/net/html_00/
online_zugreifen.htm
