Siemens RWF55.51A9 User Manual

28/93
Building Technologies Division User Manual RWF55... CC1U7867en
Infrastructure & Cities Sector 5 Operating modes 05.11.2013
5.4 Predefined setpoint
The setpoints (SP1, SP2 or dSP) are predefined within the selected setpoint limits via the
buttons or the ACS411 software.
It is possible to shift the setpoint using either an analog or a binary signal, to change it
via an external contact, or to influence it using a weather-compensated method.

Reference!
See chapter 8.8 Binary functions binF.
Setpoint
changeover
Shifting
Binary input
D1
Information
SP1
Analog via InP2 Open

Reference!
See chapter 5.4.1 Setpoint changeover
SP1/SP2, or shifting analog via InP2
SP2
Analog via InP2 Closed
SP1
Open

Reference!
See chapter 5.4.2 Setpoint changeover
SP1 / external setpoint via InP2
External setpoint
via InP2
Closed
Setpoint SP1 analog via
InP2,
no binary shifting
Open

Reference!
See chapter 5.4.3 Setpoint shifting SP1
analog via InP2 / binary via dSP
Setpoint SP1 analog via
InP2, binary shifting
about setpoint dSP
Closed
External setpoint via
InP2,
no binary shifting
Open

Reference!
See chapter 5.4.4 External setpoint,
setpoint shifting binary via dSP
External setpoint via
InP2,
binary shifting about
setpoint dSP
Closed
