Siemens RWF55.51A9 User Manual

41/93
Building Technologies Division User Manual RWF55... CC1U7867en
Infrastructure & Cities Sector 6 Operation 05.11.2013
6.3 User level
This level is started from the basic display.
Setpoints SP1, SP2 or dSP can be altered.
The values of the analog inputs InP1, InP2, InP3 and SPE (external setpoint) and InP3
(actual angular positioning between 0...100%) can be displayed.
Changing SP1, SP2 or dSP.
*
From the basic display, press
so that OPr appears
*
Press so that SP1 appears
*
Press and SP1 flashes
*
Press
or
to adjust the required setpoint and press
to confirm
SP2 only appears if setpoint changeover is set (binary input bin1 = 1).
*
From the basic display, press
so that OPr appears
*
Press so that SP1 appears
*
Press
to change over to SP2
*
Press and SP2 flashes
*
Press
or
to adjust the required setpoint and press
to confirm
dSP only appears if setpoint shifting is set (binary input bin1 = 2).
*
From the basic display, press
so that OPr appears
*
Press so that SP1 appears
*
Press
to change over to dSP
*
Press and dSP flashes
*
Press
or
to adjust the required setpoint and press
to confirm
Timeout after about 180 seconds.

Note!
If the setpoint is not stored, the basic display changes after the timeout tout and the
former setpoint is maintained.
The value changes only within the permitted range.
Changing the
setpoints
SP1
SP2
dSP
Timeout
