70/93
Building Technologies Division User Manual RWF55... CC1U7867en
Infrastructure & Cities Sector 11 Modbus interface 05.11.2013
11.3 Configuration level
Address Access Data type Signal reference Parameter
0x3426 R/W Float
SCL1
Start of display input 1
0x3428 R/W Float
SCH1
End of display input 1
0x3432 R/W Float
SCL2
Start value input 2
0x3434 R/W Float
SCH2
End value input 2
0x3486 R/W Float
SPL
Start of setpoint limitation
0x3488 R/W Float
SPH
End of setpoint limitation
0x342A R/W Float
OFFS1
Offset input E1
0x3436 R/W Float
OFFS2
Offset input E2
0x343A R/W Float
OFFS3
Offset input E3
0x1063 R/W Word
FnCt
Ramp function
0x1065 R/W Float
rASL
Ramp slope
0x1067 R/W Float
toLP
Tolerance band ramp
0x1069 R/W Float
rAL
Limit value
0x1075 R/W Float
dtt
Remote Detection Timer
0x1077 R/W Float
dF1
Filter constant input 1
0x1079 R/W Float
dF2
Filter constant input 2
0x107B R/W Float
dF3
Filter constant input 3
0x107D R/O Float
oLLo
Lower working range limit
0x107F R/O Float
oLHi
Upper working range limit
0x106D R/W Word
FnCt
Alarm relay function
0x106F R/W Float
AL
Alarm relay limit value (limit value alarm)
0x1071 R/W Float
HYSt
Alarm relay hysteresis
11.4 Remote operation
Address Access Data type Signal reference Parameter
0x0500 R/W Word REM Activation remote operation *
0x0501 R/W Word
rOFF
Controller OFF in remote setpoint **
0x0502 R/W Float
rHYS1
Switch-on threshold remote
0x0504 R/W Float
rHYS2
Switch-off threshold down remote
0x0506 R/W Float
rHYS3
Switch-off threshold up remote
0x0508 R/W Float
SPr
Setpoint remote
0x050A R/W Word RK1 Burner release remote operation
0x050B R/W Word RK2 Relay K2 remote operation
0x050C R/W Word RK3 Relay K3 remote operation
0x050D R/W Word RK6 Relay K6 remote operation
0x050E R/W Word
rStEP
Step-by-step control remote operation
0x050F R/W Float
rY
Angular positioning output remote operation
0x0511 R/W Float
rHYS4
Switch-on threshold remote (cooling)
0x0513 R/W Float
rHYS5
Switch-off threshold down remote (cooling)
0x0515 R/W Float
rHYS6
Switch-off threshold up remote (cooling)
Legend
* = Local
** = Controller OFF
