Siemens RWF55.51A9 User Manual

32/93
Building Technologies Division User Manual RWF55... CC1U7867en
Infrastructure & Cities Sector 5 Operating modes 05.11.2013
5.4.4 External setpoint, setpoint shifting binary via dSP
binI = 2
binI = 1
b
inI = 0, 3
SPL oLLo /
Active setpoint
SPH oLHi /
Function of binary input D1:
Setpoint changeover:
2 0
1
Binary input circuit D1:
See chapter 4.3 Assignment of terminals
See chapter
8.2 Analog input
InP2
Function : = 1 InP2 FnC2
dSP
0,0
Figure 15: External setpoint, setpoint shifting binary via dSP
