7.4 Drive data sets
F-TM ServoDrive
62 Equipment Manual, 02/2020, A5E47579503-AA
7.4 Drive data sets
Introduction
So that you can optimally handle the requirements of drive technology, the F-TM ServoDrive
drive system is compatible with motors (Dunkermotoren, ebm-papst) and connecting cables
(Harting, KnorrTec) of proven product partners of Siemens. This allows you to optimally
combine suitable products from proven product partners for your individual application.
You can find more information about the Siemens Product Partner Program in the Internet
(
https://new.siemens.com/global/en/products/drives/sinamics/servo-drive-system-simatic-
micro-drive.html).
Drive data record
The motor or drive of the F-TM ServoDrive drive system is configured using a drive data
record (DDS). A drive data record contains the settings and information for the following
drive components:
● Motor
● Gearbox
● Thermal model
● Brake module
Note
The description "drive" means the combination of motor, encoder and additional built
-on
accessories such as a gearbox and holding brake.
Motor
You can find the settings for the motor in the "Parameters" > "Drive" > "Motor" area.
The F-TM SevoDrive drive system supports PMSM motors. You specify important basic data
and reference data of the motor.
Observe the information and notes in the help or in the tooltips of the individual parameters.
You can also find detailed information and descriptions for the drive parameters in the
Product Information (https://support.industry.siemens.com/cs/ww/en/view/109773204
).
Motor encoder
The motor encoder is used for the closed-loop speed control of the drive. The encoder
values are transferred from the TM ServoDrive to the CPU in the ProfiDrive telegram,
independent of the encoder type.
The F-TM ServoDrive only supports motors with IQ-Encoders as encoders.
