Interrupts, error messages and diagnostics and system alarms
10.2 Diagnostics
F-TM ServoDrive
Equipment Manual, 02/2020, A5E47579503-AA
93
10.2.2 Active messages
Pending faults and alarms
"Active messages" shows the currently pending faults and alarms in the F-TM ServoDrive.
Faults must be acknowledged after the cause has been corrected.
Procedure
To display the active messages, follow these steps:
1. Select the F-TM ServoDrive in the project tree and go to "Online & diagnostics".
2. In the "Diagnostics" folder, select the "Active messages" area.
Faults and alarms
Column
Description
Fault number
Number of the fault
Description
Description of the fault
The F-TM ServoDrive supports the following faults.
Fault number
Description
1000
Overvoltage in the intermediate circuit
1001
Undervoltage in the intermediate circuit
1003
Shutdown due to overcurrent switch-off of a phase
1019
Braking resistor/motor holding brake interrupted
1032
Temperature measured values implausible
1035
Permitted temperature at the motor end stage exceeded
1036
Permitted temperature at the motor winding exceeded
1037
Permissible temperature of the braking resistor exceeded
1039
Connection to IQ encoder interrupted
Acknowledge faults
To acknowledge all active faults, click the "Acknowledge faults" button.
