Siemens SIMATIC ET 200SP F-TM User Manual

Interrupts, error messages and diagnostics and system alarms
10.2 Diagnostics
F-TM ServoDrive
94 Equipment Manual, 02/2020, A5E47579503-AA
Alarms
Column
Description
Alarm number
Number of the warning
Description
Description of the warning
The F-TM ServoDrive supports the following warnings.
Alarm number
Description
2000
Voltage in the intermediate circuit shortly before shutdown
2001 STO shutdown active
2002
Warning threshold when motor end stage temperature is exceeded
2003
Warning threshold when motor winding temperature is exceeded
2004
Thermal overload of the motor end stage
2005
Thermal overload of the brake chopper
10.2.3 Drive diagnostics
You can find online information on important current drive diagnostics data and drive service
data in the "Drive diagnostics" area under "Online & diagnostics" in the context of the drive.
Note
All drive diagnostics are only available online. They are automatically updated in the user
interface.
You will find diagnostic information on the following points in the "Drive diagnostics" area:
● Status bits
● Operating values
● Encoders
● Temperatures
● Inputs
Properties of drive diagnostics
Drive diagnostics
● Show the current values of various parameters
● Are cyclically updated
● Are read-only.
