Operating a project
8.7 Closing the project
Mobile Panels 2nd Generation
208 Operating Instructions, 09/2018, A5E33876626-AC
An infotext that is available for an operating object is displayed with the <Help> key on the
screen keyboard. Depending on the configuration, infotext may also be accessed with an
operating object. Please refer to your system documentation for additional information.
● Operating element with configured infotext is selected.
1. Press the <HELP> key.
The infotext for the screen or operating object is displayed.
Note
The configuration engineer can configure infotext for an I/O field and the associated
screen. You can switch between two infotexts by touching the infotext window.
2. Close the window with the infotext.
Closing the project
Procedure
1. Use the corresponding operator control object to close the project.
The following only applies to fail-safe Mobile Panels: When PROFIsafe communication is
active, the "Confirm logoff" dialog is displayed. Confirm the logoff in the corresponding
dialog.
2. Wait for the Start Center to be displayed.
3. Pull out the connecting cable if required, as described in section
"Unplugging the connecting cable (Page 211)".
