Technical specifications
11.5 Mechanical ambient conditions
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
223
The following table shows the unwanted emissions from electromagnetic fields in
accordance with EN 55016, Limit Value Class A, Group 1, measured at a distance of
10 m.
< 40 dB (μV/m) quasi-peak
< 47 dB (μV/m) quasi-peak
Emission of radio interference
Before you connect the HMI device and any connection box to the public electricity network,
you must make sure that they comply with Limit Value Class B in accordance with
EN 55022.
EMC information in section "Notes about usage (Page 37)".
Mechanical ambient conditions
11.5.1
The following information applies to an HMI device and connection box transported and
stored in its original packaging. The devices were tested based on IEC 60721-3-2 Class 2M4
with the following amendments and limitations:
Vibration to IEC 60068-2-6 5 … 8.4 Hz, deflection 3.5 mm
8.4 … 500 Hz, acceleration 1 g
2
The following information applies to the HMI device and to the connection box. The devices
are designed for operation in a location protected from the effects of the weather. The
devices were tested based on IEC 60721-3-3 Class 3M3 with the following amendments and
limitations:
Vibration to IEC 60068-2-6 5 ... 8.4 Hz, deflection 3.5 mm
8.4 ... 200 Hz, acceleration 1 g
2
