Installing system components
3.4 Attaching the KTP Mobile wall-mounting bracket
Mobile Panels 2nd Generation
48 Operating Instructions, 09/2018, A5E33876626-AC
Mounting position and clearance
Mounting position
The KTP Mobile wall-mounting bracket is designed for vertical walls or one of the following
types of enclosures:
● Mounting cabinets
● Control cabinets
● Control panels
● Consoles
The wall-mounting bracket can be installed vertically or tilted slightly backwards.
The wall-mounting bracket must be mounted securely
If the wall-mounting bracket is not mounted securely, it can fall off together with the HMI
device and the connecting cable. This can result in personal injury or material damage.
Select a mounting location with sufficient load-carrying capacity for the total weight of the
wall-mounting bracket, HMI device and connecting cable. Choose the corresponding fixing
material.
Weight information is available in section "Technical specifications (Page 233)".
Do not attach the wall-mounting bracket to a moving or vibrating enclosure
When attaching the wall-mounting bracket to a moving or vibrating enclosure, the Mobile
Panel can fall out of the wall-mounting bracket.
Only attach the wall-mounting bracket on a motionless and vibration-free enclosure.
Note
A position at eye level facilitates operation of the Mobile Panel when it is mounted in the
wall
-mounting bracket.
If you want to operate the HMI device in a stationary position, note the length of the
connecting cable to the connection box when selecting the location for the KTP Mobile wall-
mounting bracket.
