Technical specifications
11.8 Technical specifications
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
235
Insulation testing, protection class and degree of protection
Insulation testing
The insulation strength is demonstrated in the type test with the following test voltages in
accordance with IEC 61131-2:
Insulation tested with (type test)
707 V DC to other circuits / to ground
Ethernet connector 1500 V AC
Protection class III according to IEC 61131-2
Protection against foreign objects and water
The device meets the degrees of protection to IEC 60529 and UL50 under the following
requirements:
● The terminal compartment cover is closed.
● The USB port is closed using a cover.
All-round
• IP65 according to IEC 60529
• Type 4X/Type 12 (indoor use only) to UL50
Applies if indicated on the nameplate
Degree of pollution and overvoltage category
The device meets the following requirements according to IEC 61131-2:2007.
Overvoltage category II
Weight You can find the information based on length on the Internet at:
HMI accessories
(https://mall.industry.siemens.com/mall/en/WW/Catalog/Products/10144445) *
Bending radius,
≥ 4-times the outside diameter of the line
Rated condition,
0 to 55 °C
* To navigate directly to the information about the connecting cable, enter the article number of the
connecting cable in the "Site Explorer" text box.
