8.4 Technical specifications
SIMATIC IPC477E
Operating Instructions, 12/2016, A5E37455003-AB
133
Environmental conditions
Climatic ambient conditions
Permitted ambient temperature during operation
Temperature, tested according to IEC 60068-2-1, IEC 60068-2-2
At an ambient temperature > 40 °C, the device must be operated in an operating area in accordance with
When installed vertically in horizontal format With HDD:
With CFast or
+5 to +35 °C
+0 to +50 °C
When installed inclined in horizontal format,
Vertical inclination max. ± 45°
With CFast or
SSD:
+0 to +50 °C
When installed upright in vertical format,
Display rotated 90° vertical from the standard position
(Power supply is located at the top)
With CFast or
SSD:
+0 to +40 °C
At an ambient temperature > 40 °C, the device must be operated in an operating area in accordance with
When installed vertically in horizontal format With HDD:
With CFast or
+5 to +35 °C
+0 to +45 °C
When installed inclined in horizontal format,
Vertical inclination max. ± 45°
With CFast or
SSD:
+0 to +40 °C
When installed upright in vertical format,
Display rotated 90° vertical from the standard position
(Power supply is located at the top)
With CFast or
SSD:
+0 to +40 °C
At an ambient temperature > 40 °C, the device must be operated in an operating area in accordance with
RAL.
When installed vertically in horizontal format With HDD:
With CFast or
+5 to +35 °C
+0 to +45 °C
When installed inclined in horizontal format,
Vertical inclination max. ± 45°
With CFast or
SSD:
+0 to +40 °C
When installed upright in vertical format,
Display rotated 90° vertical from the standard position
(Power supply is located at the top)
With CFast or
SSD:
+0 to +40 °C
Temperature during storage/transport
Storage/transport, gradient
-20 °C to +60 °C
Max. 20 °C/h, no condensation
: The ambient temperature must be reduced by 5 °C for the setting "Performance Optimized" (see
Assigning CPU power consumption parameters (Page 86)).
