Siemens SIMATIC IPC477E User Manual

SIMATIC IPC477E
Operating Instructions, 12/2016, A5E37455003-AB
167
Markings and symbols
B
B.1
Overview
The following tables show all the symbols which may be found on your SIMATIC industrial
PC, SIMATIC industrial monitor or SIMATIC Field PG in addition to the symbols which are
explained in the operating instructions.
The symbols on your device may vary in some details from the symbols shown in the
following tables.
B.2
Safety
Symbol
Meaning
Symbol
Meaning
Warning, observe the supplied docu-
mentation.
Lock is closed
Attention, radio equipment
Lock is open
Disconnect the power plug before
opening
Opening for Kensington lock
Attention ESD (Electrostatic sensitive
device)
Warning of hot surface
B.3
Operator controls
Symbol
Meaning
Symbol
Meaning
On/off switch, without electrical isola-
tion
Eject CD/DVD
On/off switch, without electrical isola-
tion
