Getting Started
20 A5E37208904-003, 04/2017
2.3
Accessories
Fuse/Type-E combination motor controller
A fuse/type-E combination motor controller/circuit breaker can be used to protect the system. Integral solid state short circuit
protection does not provide branch circuit protection. Branch circuit protection must be provided in accordance with the
National Electrical Code and any additional local codes. Refer to the following table for the selection of fuses, type-E
combination motor controllers, and circuit breakers:
SINAMICS V90 PN 200 V variant
SINAMICS V90 PN
Recommended fuse
Type-E combination motor controller
1)
Power
supply
Frame
size
Rated
power
(kW)
CE-compliant
UL/cUL-
compliant
listed (JDDZ)
fuse
Rated
current
(A)
Rated volt-
age (VAC)
Rated
power
(hp)
Article number
1-phase,
200 VAC to
240 VAC
FSB 0.1 3NA3 801 (6
A)
6 A 2.8 to 4 230/240 1/3 3RV 2011-
1EA10
0.2 3NA3 801 (6
A)
6 A 2.8 to 4 230/240 1/3 3RV 2011-
1EA10
0.4 3NA3 803 (10
A)
10 A 5.5 to 8 230/240 1 3RV 2011-
1HA10
FSC 0.75 3NA3 805 (16
A)
20 A 9 to 12.5 230/240 2 3RV 2011-
1KA10
3-phase,
200 VAC to
240 VAC
FSB 0.1 3NA3 801 (6
A)
6 A 2.8 to 4 230/240 3/4 3RV 2011-
1EA10
0.2 3NA3 801 (6
A)
6 A 2.8 to 4 230/240 3/4 3RV 2011-
1EA10
0.4 3NA3 803 (10
A)
10 A 2.8 to 4 230/240 3/4 3RV 2011-
1EA10
FSC 0.75 3NA3 805 (16
A)
20 A 5.5 to 8 230/240 2 3RV 2011-
1HA10
FSD 1.0 3NA3 805 (16
A)
20 A 7 to 10 230/240 3 3RV 2011-
1JA10
1.5 3NA3 810 (25
A)
25 A 10 to 16 230/240 5 3RV 2011-
4AA10
2.0 3NA3 810 (25
A)
25 A 10 to 16 230/240 5 3RV 2011-
4AA10
1)
The above types for type-E combination motor controllers are listed in compliance with both CE and UL/cUL standards.
SINAMICS V90 PN 400 V variant
SINAMICS V90 PN
Recommended fuse type
Type-E combination motor controller
1)
Power
supply
Frame
size
Rated
power
(kW)
CE-compliant
UL/cUL-
compliant
listed (JDDZ)
fuse
Rated
current (A)
Rated volt-
age (VAC)
Rated
power
(hp)
Article number
3-phase,
380 VAC to
480 VAC
FSAA 0.4 3NA3 801-6
(6 A)
10 A 2.2 to 3.2 380/480 0.5 3RV 2021-
1DA10
FSA 0.75 3NA3 801-6
(6 A)
10 A 2.8 to 4 380/480 1 3RV 2021-
1EA10
1.0 3NA3 803-6
(10 A)
10 A 3.5 to 5 380/480 1.34 3RV 2021-
1FA10
FSB 1.5 3NA3 803-6
(10 A)
15 A 5.5 to 8 380/480 2 3RV 2021-
1HA10
2.0 3NA3 805-6
(16 A)
15 A 11 to 16 380/480 2.68 3RV 2021-
4AA10
