Master sign-of-life, bit 2
Master sign-of-life, bit 3
G1_STW encoder 1 control word
Selects the function to be activate (with bit value = 1)
G1_STW.1
Start/stop/read selected function
G1_STW.5
G1_STW.6
G1_STW.7 Mode of the function to be activated
1 = Flying measurement
0 = Search for reference mark
1 = Request value cyclic transfer of the absolute position value in Gn_XIST2
1 = Request parking encoder
G1_STW.15
= Acknowledge encoder fault
1 = Traversing block selection, bit 0
1 = Traversing block selection, bit 1
1 = Traversing block selection, bit 2
1 = Traversing block selection, bit 3
1 = Traversing block selection, bit 4
1 = Traversing block selection, bit 5
