Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
72 A5E37208904-003, 04/2017
Signal
Description
STW1.11
1 = Setpoint inversion
STW1.12
Reserved
STW1.13
Reserved
STW1.14
Reserved
STW1.15
Reserved
6.3.2
STW2 control word (for telegrams 2, 3, 5)
Signal
Description
STW2.0 Reserved
STW2.1
Reserved
STW2.2
Reserved
STW2.3
Reserved
STW2.4
Reserved
STW2.5
Reserved
STW2.6
Reserved
STW2.7
Reserved
STW2.8
1 = Traverse to fixed endstop
STW2.9
Reserved
STW2.10
Reserved
STW2.11
Reserved
STW2.12
Master sign-of-life, bit 0
STW2.13
Master sign-of-life, bit 1
STW2.14
Master sign-of-life, bit 2
STW2.15
Master sign-of-life, bit 3
6.3.3
STW1 control word (for telegrams 102, 105)
Note
When telegram 105 is used, STW1.4, STW1.5, and
STW1.6 are disabled.
Note
STW1.10 must be set to 1 to allow PLC to control the drive.
Signal
Description
STW1.0
= ON (pulses can be enabled)
0 = OFF1 (braking with ramp-function generator, then pulse suppression and ready for switching on)
STW1.1 1 = No OFF2 (enable is possible)
0 = OFF2 (immediate pulse suppression and switching on inhibited)
STW1.2 1 = No OFF3 (enable is possible)
0 = OFF3 (braking with the OFF3 ramp p1135, then pulse suppression and switching on inhibited)
STW1.3 1 = Enable operation (pulses can be enabled)
0 = Inhibit operation (suppress pulses)
STW1.4 1 = Operating condition (the ramp-function generator can be enabled)
0 = Inhibit ramp-function generator (set the ramp-function generator output to zero)
STW1.5 1 = Continue ramp-function generator
0 = Freeze ramp-function generator (freeze the ramp-function generator output)
