Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
A5E37208904-003, 04/2017
25
Article No.
6SL3210-5FE...
10-
4UF0
10-
8UF0
11-
0UF0
11-
5UF0
12-
0UF0
13-
5UF0
15-
0UF0
17-
0UF0
Frame size
FSAA
FSA
FSA
FSB
FSB
FSC
FSC
FSC
Power sup-
ply
Voltage/frequency
Three phase 380 VAC to 480 VAC, 50/60 Hz
Permissible voltage fluc-
tuation
-15% to +10%
Permissible frequency
fluctuation
-10% to +10%
Permissible supply con-
figuration
TN, TT, IT
Rated input current (A)
1.5
2.6
3.8
6.6
9.8
13.8
15.8
16.5
Power supply capacity
(kVA)
1.7 3.0 4.3 7.6 11.1 15.7 18.0 18.9
Inrush current (A)
8.0
8.0
8.0
4.0
4.0
2.5
2.5
2.5
Cooling method
Self-cooled
Fan-cooled
Mechanical
design
Outline dimensions (W x
H x D, mm)
60 x
180 x
200
80 x 180 x 200 100 x 180 x 220 140 x 260 x 240
Weight (kg)
1.5
1.9
1.9
2.5
2.5
5.0
5.5
5.75
1)
The values here are calculated at rated load.
2.5.2
Technical data - servo motors
General technical data
Parameter
Description
Type of motor
Permanent-magnet synchronous motor
Cooling
Self-cooled
Relative humidity [RH]
90% (non-condensing at 30°C )
Installation altitude [m]
≤ 1000 (without power derating)
Thermal class
B
Vibration severity grade
A (according to IEC 60034-14)
Shock resistance [m/s
2
]
25 (continuous in axial direction); 50 (continuous in radial direction); 250
(in a short time of 6 ms)
Bearing lifetime [h]
> 20000
1)
Paint finish
Black
Protection degree of shaft
IP 65, with shaft oil seal
Type of construction
IM B5, IM V1, and IM V3
Positive rotation
Clockwise (default setting in servo drives)
Certification
CE, EAC
1)
This lifetime is only for refere
nce. When a motor keeps running at rated speed under rated load, replace its bearing after
20,000 to 30,000 hours of service time. Even if the time is not reached, the bearing must be replaced when unusual
noise, vibration, or faults are found.
