Description
1.5 Type plates
SIMOTION D410-2
Manual, 02/2012
19
The interface to the power module (PM) is located at the rear of the SIMOTION D410-2.
Figure 1-5 Power Module Interface (PM-IF)
See also
Interfaces (Page 33)
1.5 Type plates
The following figure shows all the information that the type plate on the module rear side
contains.
Module designation
Order number
Serial number
HW version
C-Tick
CULUS
Figure 1-6 SIMOTION D410-2 DP type plate
Note
You might need to access the information provided on the rear-mounted type plate on the
module after it has been installed. We recommend that you make a note of any required
information prior to the installation because the type plate is hidden in the installed state.
