Technical data
4.2 Mechanical and climatic ambient conditions
SIMOTION D410-2
60 Manual, 02/2012
4.2 Mechanical and climatic ambient conditions
Conditions of use
SIMOTION D410-2 is designed for use in stationary, weather-protected locations.
SIMOTION D410-2 meets the conditions of use for Class 3C3 in accordance with
DIN EN 60721-3-3 (operating locations with high traffic densities and in the immediate
vicinity of industrial equipment with chemical emissions).
Use prohibition
Without additional measures, SIMOTION D410-2 may not be used in
● Locations with a high percentage of ionizing radiation
● Locations with extreme operating conditions, e.g.
– Dust accumulation
– Corrosive vapors or gases
● In systems that require special monitoring, e.g.
– Elevator installations
– Electrical systems in particularly hazardous rooms
An additional measure for using SIMOTION D410-2 can, for example, be installation in
cabinets.
Ambient operating conditions for the operation
SIMOTION D410-2 may be used under the following ambient conditions:
Table 4- 2 Environmental requirements
Ambient conditions Application range Remarks
Climatic ambient conditions
Climate class 3K3 According to EN 60721-3
Permissible ambient temperature 0 to +55° C, up to 2000 m above
sea level
Maximum installation altitude 2000 m to max. 4000 m above sea
level
As of an altitude of 2000 m, the maximum
ambient temperature decreases by 7° C every
1000 m increase in altitude.
Relative humidity 5% to 95%
Condensation, icing, drip, spray
and splash water
Not permissible
Atmospheric pressure 620 to 1060 hPa Corresponding height 4000 m - 0 m above sea
level
