6.2 TM31 terminal module
Properties
The TM31 terminal module allows you to expand the number of available digital I/Os as well
as the number of analog I/Os within a drive system. The TM31 is connected via DRIVE-
CLiQ. It has 2 DRIVE-CLiQ interfaces for this.
Interfaces
The TM31 contains the following terminals:
Table 6- 2 Interface overview of the TM31
Interface Number
Digital inputs 8
Bidirectional I/Os 4
Relay outputs with changeover contact 2
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
CAUTION
The 50 mm clearances above and below the component must be observed.
Additional references
For further information on the TM31 terminal module, see the
SIMOTION D410-2
Commissioning and Hardware Installation Manual.
