SIMOTION D410-2
Manual, 02/2012
33
Interfaces
3
3.1 Overview of interfaces
This chapter describes the SIMOTION D410-2 DP interfaces. The arrangement of the
interfaces on the module can be found in the SIMOTION D410-2 DP representation
(Page 18) chapter.
Available interfaces
Table 3- 1 Overview of the available SIMOTION D410-2 DP interfaces
Interface Type Connector type
X100 DRIVE-CLiQ interface (DQ) 8-pin RJ45plus socket to connect DRIVE-
CLiQ nodes
X21 PROFIBUS DP/MPI interface 9-pin SUB-D socket to connect to
PROFIBUS DP or MPI
X24 PROFIBUS DP interface 9-pin SUB-D socket to connect to
PROFIBUS DP
X23 Encoder interface (ENC) 15-pin SUB-D socket for connecting HTL,
TTL and SSI encoders.
X120 Temperature sensor connection, fail-
safe digital inputs
12-pin spring-loaded terminal
X121 Isolated digital inputs, fast digital I/Os 12-pin spring-loaded terminal
X130 Isolated digital input, fail-safe digital
output
8-pin spring-loaded terminal
X131 Fast digital I/Os, analog input 8-pin spring-loaded terminal
X124 Power supply connection 4-pin screw-type terminal connection
X127 P1 Ethernet interface (PN/IE) 8-pin RJ45plus socket for Ethernet
connection (LAN)
T0, T1, T2
and G
Measuring sockets Sockets to output analog signals
PM-IF Power Module Interface 8-pin direct connector to connect to a
blocksize power module
Non-usable interfaces
Table 3- 2 Overview of the unavailable SIMOTION D410-2 DP interfaces
Interface Designation Connector type
Interface for BOP BOP 8-pin multipoint connector
