Technical data
4.4 Interfaces and performance features
SIMOTION D410-2
64 Manual, 02/2012
Integrated drive control
Table 4- 8 Controls for integrated drives
Max. number of axes for integrated
drive control
(servo / vector / V/f)
1 / 1 / 1 (alternative)
drive control based on SINAMICS S120 CU310-2, firmware
version V4.x
4.4.2 Communication
Interfaces
Table 4- 9 Interfaces
DRIVE-CLiQ interface 1
Ethernet interface 1
PROFIBUS interface 2
• Equidistant and isochronous
• Can be configured as master or slave
Address space
Table 4- 10 Address space
Logical I/O address space 8 KB
Physical I/O address space, each PROFIBUS interface,
each inputs and outputs
1 KB
Permanent process image for BackgroundTask (I/O variables) 64 bytes
Additional configurable process image for each cyclic task (I/O
variables)
Yes
Address space for each PROFIBUS DP station 244 bytes
Address space per SINAMICS Integrated (PROFIBUS
Integrated)
512 bytes
