Rules for handling backup batteries
WARNING
Risk of ignition, explosion, and combustion
Incorrect handling of backup batteries can result in a risk of ignition, explosion, and
combustion.
The regulations of DIN EN 60086‑4, in particular regarding avoidance of mechanical or
electrical tampering of any kind, must be complied with.
●
Do not recharge
● Do not throw into a fire
● Do not solder on the body of the cell
● Do not open
● Only replace with identical types
● Only use a replacement from Siemens (see Section Available spare parts and
accessories (Page 135))
Always try to return old batteries to the manufacturer or deliver these to a registered recycling
company where possible.
For information on shipping and storage of backup batteries, see Section Shipping and storage
conditions
(Page 77).
7.3 TB30 terminal board
7.3.1 Description
The TB30 terminal board is a terminal expansion module for SIMOTION D4x5‑2. The module
is inserted in the option slot of the D4x5‑2 control unit.
Table 7-3 Interface overview of the TB30
Type Quantity
Digital inputs 4
Digital outputs 4
Analog inputs 2
Analog outputs 2
Supplementary system components
7.3 TB30 terminal board
SIMOTION D4x5-2
102 Manual, 04/2014
