2.8 CompactFlash card
2.8.1 Usage and function of the CompactFlash Card
The CompactFlash card (CF card) is inserted in the slot with the designation CF (X109
interface).
&RPSDFW)ODVKFDUG
'[
2SHUDWLQJHOHPHQWVFRYHUHG
2SHUDWLQJHOHPHQWVZLWKRXWFRYHU
&RYHU
Figure 2-7 Slot for CompactFlash card
The CF card does not extend beyond the housing. An ergonomic recessed grip enables the
CF card to be removed.
Characteristics of the CF card
The
CF card is essential for operation of the SIMOTION D4x5‑2. The CF card is not supplied
with the SIMOTION D4x5‑2 and must be ordered separately.
Description
2.8 CompactFlash card
SIMOTION D4x5-2
38 Manual, 04/2014
