4.4 Digital I/Os
4.4.1 Properties
Interface characteristics
The digital I/Os on the X122, X132 and X142 connectors are for the connection of sensors
and actuators.
Table 4-7 Wiring of X122, X132 and X142
Features Type
Connector type 14-way spring-loaded terminal
Connectable cable types and conductor cross-
sections
Rigid 0.2 mm² … 1.5 mm²
Flexible 0.2 mm² … 1.5 mm²
Flexible, with wire-end ferrule without plastic
sleeve
0.25 mm² … 1.5 mm²
Flexible, with wire-end ferrule with plastic
sleeve
0.25 mm² … 0.75 mm²
AWG / kcmil 24 … 16
Stripped length 10 mm
Tool Screwdriver 0.4 x 2.0 mm
Max. cable length 30 m
Max. current carrying capacity (ground) 6 A
Interfaces
4.4 Digital I/Os
SIMOTION D4x5-2
58 Manual, 04/2014
