Representati
on
Pin Assignment in 10/100 Mbit mode Assignment in 1 Gbit mode
8 - - - - - - Reserved, do
not use
DD- B Bidirectional
pair D-
I = Input; O = Output; B = Bidirectional
1)
Autocrossing functionality (if required, transmit and receive lines switch over)
Note
The
MAC addresses are imprinted on an adhesive label that is located behind the protective
cover and can be seen from the front.
4.7 PROFIBUS DP interfaces
Characteristics of the interface
Table 4-16
Interfaces X126 and X136
Characteristics Type
Connector type 9‑pin Sub‑D socket
Cable type PROFIBUS cable
Max. cable length 100 m at 12 Mbit/s
Interfaces
4.7 PROFIBUS DP interfaces
SIMOTION D4x5-2
70 Manual, 04/2014
