Siemens SIMOTION D435-2 User Manual

Additional references
You will find detailed information on the individual topics in the following table:
Table 3-4
References
Subject Reference
Setting of the operating modes ●
SIMOTION SCOUT Configuration Manual
Upgrading devices (device update tool) ●
Upgrading SIMOTION Devices Operating
Instructions and
● SIMOTION D4x5‑2 Commissioning and Hardware
Installation Manual
● Creating diagnostic data and
●
Saving/restoring non‑volatile SIMOTION
data
● SIMOTION D4x5‑2 Commissioning and Hardware
Installation Manual
3.2.2 DIAG button
Layout
The DIAG button is located behind the blanking cover on the SIMOTION D4x5‑2.
Function
The
diagnostic data and non-volatile SIMOTION data is backed up on the CompactFlash card
via the DIAG button.
The DIAG button function therefore corresponds to the function of switch position "D" of the
Service selection switch.
Various options are available for backing up the data:
● Option 1: Backup during operation (in STOP/STOPU/RUN operating state)
● Option 2: Backup during the module startup
With option 1, the DIAG button only has to be pressed briefly to trigger the data backup. The
DIAG button is therefore preferable to switch position "D" of the Service selection switch.
With option 2, the DIAG button has to be pressed until the boot procedure is completed. As
this can take 20‑30 seconds, switch position "D" is preferable here.
Additional references
For detailed information on creating diagnostic data and backing up / restoring non-volatile
SIMOTION data, refer to the
SIMOTION D4x5‑2 Commissioning and Hardware Installation
Manual.
Operator control (hardware)
3.2 Operator controls
SIMOTION D4x5-2
48 Manual, 04/2014
