4.8 Slot for CompactFlash card
Characteristics
Connector type: 50-pin connector
This interface should only be used to insert a special SIMOTION CompactFlash card (CF card).
&RYHU
6ORWZ
LWKLQVHUWHG&)FDUG
Figure 4-9 Slot for the CompactFlash card
Consult the relevant references for detailed information about the SIMOTION CompactFlash
card in Section CompactFlash card
(Page 39).
4.9 Measuring sockets
Application
The measuring sockets X141 (T0, T1 and T2) are on the lower side of the module and are
used to output analog signals. Any interconnectable signal can be output via SINAMICS on
every measuring socket on the control unit.
Interfaces
4.9 Measuring sockets
SIMOTION D4x5-2
Manual, 04/2014 73
