Interfaces
4
4.1 Interface overview
This section describes the interfaces of the SIMOTION D4x5-2.
The position of the interfaces on the module can be found in the following sections:
●
Representation of SIMOTION D425-2 DP and D435-2 DP (Page 31)
● Representation of SIMOTION D425-2 DP/PN and D435-2 DP/PN (Page 33)
● Representation of SIMOTION D445-2 DP/PN and D455-2 DP/PN (Page 35)
Available interfaces
Table 4-1 Overview of available interfaces
Interface Designation Connector type
DRIVE-CLiQ interface X100 DRIVE‑CLiQ socket
DRIVE-CLiQ interface X101 DRIVE‑CLiQ socket
DRIVE-CLiQ interface X102 DRIVE‑CLiQ socket
DRIVE-CLiQ interface X103 DRIVE‑CLiQ socket
DRIVE-CLiQ interface
(not for SIMOTION D425-2)
X104 DRIVE‑CLiQ socket
DRIVE-CLiQ interface
(not for SIMOTION D425-2)
X105 DRIVE‑CLiQ socket
Ethernet interface PN/IE X127 P1 RJ45 socket connector
PN/IE OP Ethernet interface
(only for SIMOTION D4x5-2 DP)
X120 P1 RJ45 socket connector
Ethernet interface PN/IE‑NET X130 P1 RJ45 socket connector
PROFINET PN IO interface
(only for SIMOTION D4x5-2 DP/PN)
X150 (P1, P2, P3) RJ45 socket connector
Digital I/Os X122, X132, X142 Mini Combicon, 3.5 mm 3x14‑pin
Power supply connector X124 Combicon, 4‑pin
PROFIBUS DP interface X126 9-pin Sub-D socket
PROFIBUS DP/MPI interface X136 9-pin Sub-D socket
Measuring sockets (T0, T1, T2, and M) X141 4-pin, socket
SIMOTION CF plug-in X109 CompactFlash card connector
Fan/battery module interface X190/X191 Fan/battery module
1. USB interface X125 USB socket
SIMOTION D4x5-2
Manual, 04/2014 51
