ESD guidelines
B
B.1 ESD definition
What does ESD mean?
Electrostatic
sensitive devices (ESDs) are individual components, integrated circuits, modules
or devices that may be damaged by either electrostatic fields or electrostatic discharge.
NOTICE
Damage caused by electric fields or electrostatic discharge
Electric fields or electrostatic discharge can result in malfunctions as a result of damaged
individual parts, integrated circuits, modules or devices.
● Only
pack, store, transport and send electronic components, modules or devices in their
original packaging or in other suitable materials, e.g conductive foam rubber or aluminum
foil.
● Only touch components, modules and devices if you are first grounded by applying one
of the following measures:
– Wearing an ESD wrist strap
– Wearing ESD shoes or ESD grounding straps in ESD areas with conductive flooring
● Only place electronic components, modules or devices on conductive surfaces (table with
ESD surface, conductive ESD foam, ESD packaging, ESD transport container).
B.2 Electrostatic charging of individuals
Any person who is not conductively connected to the electrical potential of the environment
can accumulate an electrostatic charge.
This figure indicates the maximum electrostatic charges that can accumulate on an operator
when he comes into contact with the indicated materials. These values comply with the
specifications in IEC 801-2.
SIMOTION D4x5-2
Manual, 04/2014 141
