NOTICE
Higher operating temperature if ventilation clearances are too small
The 80 mm clearances above and below the components must be observed.
The unit protects itself from overheating by shutting down.
The
ventilation clearance is measured from the lower edge of the module, i.e. the fan/battery
module is not included in the dimension.
7.5.2.2 List of interfaces
The CX32‑2 has the following interfaces:
●
4 DRIVE-CLiQ interfaces
● 4 digital inputs/outputs
● 6 digital inputs
● Power supply connector
Available interfaces
Table 7-19 Overview of available interfaces
Interface Designation Connector type
DRIVE-CLiQ interface X100 DRIVE‑CLiQ socket
DRIVE-CLiQ interface X101 DRIVE‑CLiQ socket
DRIVE-CLiQ interface X102 DRIVE‑CLiQ socket
DRIVE-CLiQ interface X103 DRIVE‑CLiQ socket
Digital inputs/outputs X122 Mini Combicon, 3.5 mm,
1x14‑pin
Power supply connector X124 Combicon, 4‑pin
Measuring sockets (T0, T1, T2, and M) X131 - X134 Sockets
Non-usable interfaces
Table 7-20
Overview of interfaces that cannot be used for the CX32‑2
Interface name Interface Connector type
RS232 interface X140 9-pin Sub-D connector
Supplementary system components
7.5 CX32-2 controller extension
SIMOTION D4x5-2
Manual, 04/2014 119
