Interface Designation Connector type
2. USB interface X135 USB socket
Option slot Sockets
Note
The third port of the PROFINET X150 P3 IO interface has an additional caption for a
SIMOTION D4x5-2 DP/PN. It is called X120 PN/IE-OP.
This designation is not relevant for SIMOTION D.
Non-usable interfaces
Table 4-2
Overview of interfaces that cannot be used for SIMOTION D
Interface name Interface Connector type
RS232 interface X140 9-pin Sub-D connector
4.2 DRIVE-CLiQ interfaces
DRIVE-CLiQ interfaces
All SINAMICS S120 drive system components, including the motors and encoders, are
interconnected
by a shared serial interface called DRIVE-CLiQ. The standardized cables and
connectors reduce the variety of different parts and cut storage costs.
DRIVE-CLiQ has the following properties:
● Automatic detection of components by the Control Unit
● Standardized interfaces to all components
● Uniform diagnostics down to the components
● Complete service down to the components
● 24 V / 450 mA per DRIVE‑CLiQ interface are provided for the connection of encoders and
measuring systems.
Note:
The DRIVE‑CLiQ cable with 24 V supply is used only for components that require this (e.g.
motors with a DRIVE‑CLiQ interface).
Interfaces
4.2 DRIVE-CLiQ interfaces
SIMOTION D4x5-2
52 Manual, 04/2014
