2.7 SYNCHROCHECK 25
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
100
2.7.8 Information List
No. Information Type of In-
formation
Comments
170.0001 >25-1 act SP >25-group 1 activate
170.0043 >25 Sync requ. SP >25 Synchronization request
170.0049 25 CloseRelease OUT 25 Sync. Release of CLOSE Command
170.0050 25 Sync. Error OUT 25 Synchronization Error
170.0051 25-1 BLOCK OUT 25-group 1 is BLOCKED
170.2007 25 Measu. req. SP 25 Sync. Measuring request of Control
170.2008 >BLK 25-1 SP >BLOCK 25-group 1
170.2009 >25direct CO SP >25 Direct Command output
170.2011 >25 Start SP >25 Start of synchronization
170.2012 >25 Stop SP >25 Stop of synchronization
170.2013 >25 V1>V2< SP >25 Switch to V1> and V2<
170.2014 >25 V1<V2> SP >25 Switch to V1< and V2>
170.2015 >25 V1<V2< SP >25 Switch to V1< and V2<
170.2016 >25 synchr. SP >25 Switch to Sync
170.2022 25-1 meas. OUT 25-group 1: measurement in progress
170.2025 25 MonTimeExc OUT 25 Monitoring time exceeded
170.2026 25 Synchron OUT 25 Synchronization conditions okay
170.2027 25 V1> V2< OUT 25 Condition V1>V2< fulfilled
170.2028 25 V1< V2> OUT 25 Condition V1<V2> fulfilled
170.2029 25 V1< V2< OUT 25 Condition V1<V2< fulfilled
170.2030 25 Vdiff ok OUT 25 Voltage difference (Vdiff) okay
170.2031 25 fdiff ok OUT 25 Frequency difference (fdiff) okay
170.2032 25 αdiff ok OUT 25 Angle difference (alphadiff) okay
170.2033 25 f1>> OUT 25 Frequency f1 > fmax permissible
170.2034 25 f1<< OUT 25 Frequency f1 < fmin permissible
170.2035 25 f2>> OUT 25 Frequency f2 > fmax permissible
170.2036 25 f2<< OUT 25 Frequency f2 < fmin permissible
170.2037 25 V1>> OUT 25 Voltage V1 > Vmax permissible
170.2038 25 V1<< OUT 25 Voltage V1 < Vmin permissible
170.2039 25 V2>> OUT 25 Voltage V2 > Vmax permissible
170.2040 25 V2<< OUT 25 Voltage V2 < Vmin permissible
170.2050 V1 = MV V1 =
170.2051 f1 = MV f1 =
170.2052 V2 = MV V2 =
170.2053 f2 = MV f2 =
170.2054 dV = MV dV =
170.2055 df = MV df =
170.2056 dα = MV dalpha =
170.2090 25 V2>V1 OUT 25 Vdiff too large (V2>V1)
170.2091 25 V2<V1 OUT 25 Vdiff too large (V2<V1)
170.2092 25 f2>f1 OUT 25 fdiff too large (f2>f1)
170.2093 25 f2<f1 OUT 25 fdiff too large (f2<f1)
170.2094 25 α2>α1 OUT 25 alphadiff too large (a2>a1)
170.2095 25 α2<α1 OUT 25 alphadiff too large (a2<a1)
