Functions
2.12 Auxiliary Functions
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
120
2.12.3.2 Transfer of Measured Values
Measured values can be transferred to a central control and storage device via port B.
The measuring range in which these values are transmitted depend on the protocol and, if necessary, additional
settings.
2.12.3.3 Information List
Protocol Transmittable measuring range, format
IEC 60870–5–103 0 to 240 % of the measured value.
IEC 61850 The primary operational measured values are transmitted.
The measured values as well as their unit format are set out in detail in manual PIXIT
7RW80.
The measured values are transmitted in „Float“ format. The transmitted measuring
range is not limited and corresponds to the operational measurement.
PROFIBUS,
Modbus, DNP 3.0
The unit format of the measured values on the device side is at first automatically gen-
erated by means of the selected nominal values of voltage within the system data.
The current unit format can be determined in DIGSI or at the device via Menu Opera-
tional Values.
The user can select via DIGSI which operational measured values (primary, secondary
or percentage) must be transmitted.
The measured values are always transmitted as 16-bit values including sign (range ±
32768). The user can define the scaling of the operational measured value to be trans-
mitted. This will result in the respective transmittable measuring range.
For further details, please refer to the descriptions and protocol profiles.
No. Information Type of In-
formation
Comments
621 Va = MV Va
622 Vb = MV Vb
623 Vc = MV Vc
624 Va-b= MV Va-b
625 Vb-c= MV Vb-c
626 Vc-a= MV Vc-a
627 VN = MV VN
629 V1 = MV V1 (positive sequence)
630 V2 = MV V2 (negative sequence)
632 Vsync = MV Vsync (synchronism)
644 Freq= MV Frequency
765 V/f = MV (V/Vn) / (f/fn)
766 V/f th= MV Calculated temperature (V/f)
832 Vo = MV Vo (zero sequence)
30800 VX = MV Voltage VX
30801 Vph-n = MV Voltage phase-neutral
