Siemens SIPROTEC 7RW80 User Manual

Technical Data
4.5 Flexible Protective Functions
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
189
4.5 Flexible Protective Functions
Measured Quantities / Operating Modes
Setting Ranges / Increments
Three-phase V, 3V
0
, V1, V2,
dV/dt, df/dt
Single-phase V, V
N
,V
x
,
Without fixed phase reference f, binary input
Measuring procedure for V Fundamental wave,
True RMS value,
Positive Sequence System,
Negative sequence system,
Zero sequence system
Pickup on Exceeding threshold or
falling below threshold
Pickup thresholds:
Voltage V, V
1
, V
2
, 3V
0
2.0 V to 260.0 V Increments 0.1 V
Displacement voltage V
N
2.0 V to 200.0 V Increments 0.1 V
Frequency for f
Nom
= 50 Hz
for f
Nom
= 60 Hz
40.0 Hz to 60.0 Hz
50.0 Hz to 70.0 Hz
Increments 0.01 Hz
Increments 0.01 Hz
Frequency change df/dt 0.10 Hz/s to 20.00 Hz/s Increments 0.01 Hz/s
Voltage change dV/dt 3 V/s to 100 V/s Increments 1 V/s
Dropout ratio > element 1.01 to 3.00 Increments 0.01
Dropout ratio < element 0.70 to 0.99 Increments 0.01
Dropout difference f 0.02 Hz to 1.00 Hz Increments 0.01 Hz
Pickup delay (standard) 0.00 s to 60.00 s Increments 0.01 s
Command delay time 0.00 s to 3600.00 s Increments 0.01 s
Dropout delay 0.00 s to 60.00 s Increments 0.01 s
