Siemens SIPROTEC 7RW80 User Manual

Functions
2.1 General
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
26
2.1.1.3 Settings
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 OSC. FAULT REC. Disabled
Enabled
Enabled Oscillographic Fault Records
143 24 V/f Disabled
Enabled
Disabled 24 Overexcit. Protection
(Volt/Hertz)
146 VECTOR JUMP Disabled
Enabled
Disabled Jump of Voltage Vector
150 27/59 Disabled
Enabled
Enabled 27, 59 Under/Overvoltage Protec-
tion
152 VT BROKEN WIRE Disabled
Enabled
Enabled VT broken wire supervision
154 81 O/U Disabled
Enabled
Enabled 81 Over/Underfrequency Protec-
tion
155 Load Restore Disabled
Enabled
Disabled Load Restoration
161 25 Function 1 Disabled
SYNCHROCHECK
Disabled 25 Function group 1
182 74 Trip Ct Supv Disabled
2 Binary Inputs
1 Binary Input
Disabled 74TC Trip Circuit Supervision
617 ServiProt (CM) Disabled
T103
DIGSI
T103 Port B usage
- FLEXIBLE FCT. 1.. 20 Flexible Function 01
Flexible Function 02
Flexible Function 03
Flexible Function 04
Flexible Function 05
Flexible Function 06
Flexible Function 07
Flexible Function 08
Flexible Function 09
Flexible Function 10
Flexible Function 11
Flexible Function 12
Flexible Function 13
Flexible Function 14
Flexible Function 15
Flexible Function 16
Flexible Function 17
Flexible Function 18
Flexible Function 19
Flexible Function 20
Please selsct Flexible Functions
