Functions
2.9 Jump of Voltage Vector
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
110
Time Delays
The time delay T DELTA PHI (address 4603) should be left at zero, unless you wish to transmit the trip indi-
cation with a delay to a logic (CFC), or to leave enough time for an external blocking to take effect.
After expiry of the timer T RESET (address 4604), the protection function is automatically reset. The reset time
depends on the decoupling policy. It must have expired before the circuit breaker is reclosed. Where the auto-
matic reset function is not used, the timer is set to ∞. The reset signal must come in this case from the binary
input (circuit breaker auxiliary contact).
The timer T BLOCK with reset delay (address 4607) helps to avoid overfunctioning when voltages are connect-
ed or disconnected. Normally the default setting need not be changed. Any change can be performed with the
DIGSI communication software (advanced parameters). It must be kept in mind that T BLOCK should not be
set less than the measuring window for vector jump measurement (150 ms).
2.9.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under "Display Additional Settings".
2.9.4 Information List
Addr. Parameter Setting Options Default Setting Comments
4601 VECTOR JUMP OFF
ON
OFF Jump of Voltage Vector
4602 DELTA PHI 2 .. 30 ° 10 ° Jump of Phasor DELTA PHI
4603 T DELTA PHI 0.00 .. 60.00 sec; ∞ 0.00 sec T DELTA PHI Time Delay
4604 T RESET 0.10 .. 60.00 sec; ∞ 5.00 sec Reset Time after Trip
4605A V MIN 10.0 .. 125.0 V 80.0 V Minimal Operation Voltage V MIN
4606A V MAX 10.0 .. 170.0 V 130.0 V Maximal Operation Voltage V
MAX
4607A T BLOCK 0.00 .. 60.00 sec; ∞ 0.15 sec Time Delay of Blocking
No. Information Type of In-
formation
Comments
5581 >VEC JUMP block SP >BLOCK Vector Jump
5582 VEC JUMP OFF OUT Vector Jump is switched OFF
5583 VEC JMP BLOCKED OUT Vector Jump is BLOCKED
5584 VEC JUMP ACTIVE OUT Vector Jump is ACTIVE
5585 VEC JUMP Range OUT Vector Jump not in measurement range
5586 VEC JUMP pickup OUT Vector Jump picked up
5587 VEC JUMP TRIP OUT Vector Jump TRIP
