Siemens SIPROTEC 7RW80 User Manual

Functions
2.4 Load Restoration
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
66
2.4.4 Information List
5587 LR4 t CB Close 0.01 .. 32.00 sec; 0 1.00 sec Load restoration element 4 CB
Close time
5588 LR4 after 81-1 YES
NO
NO Load restoration element 4 after
81-1
5589 LR4 after 81-2 YES
NO
NO Load restoration element 4 after
81-2
5590 LR4 after 81-3 YES
NO
NO Load restoration element 4 after
81-3
5591 LR4 after 81-4 YES
NO
NO Load restoration element 4 after
81-4
No. Information Type of In-
formation
Comments
17330 >LR Block SP >Load restoration Block
17331 >LR Break SP >Load restoration break
17332 >LR Process SP >Load restoration Process
17333 >LR Reset SP >Load restoration Reset
17334 LR OFF OUT Load restoration is OFF
17335 LR Successful OUT Load restoration successful
17336 LR Block OUT Load restoration Block
17337 LR Break OUT Load restoration break
17338 LR Process OUT Load restoration Process
17339 LR1 Start OUT Load restoration element 1 Start
17340 LR1 Pickup OUT Load restoration element 1 Pickup
17341 LR1 CB Close OUT Load restoration element 1 CB Close
17343 LR1 Active OUT Load restoration element 1 Active
17344 LR1 Set-Error OUT Load restoration element 1 Setting Error
17345 LR1 Monitor OUT Load restoration element 1 monitor mode
17346 LR2 Start OUT Load restoration element 2 Start
17347 LR2 Pickup OUT Load restoration element 2 Pickup
17348 LR2 CB Close OUT Load restoration element 2 CB Close
17350 LR2 Active OUT Load restoration element 2 Active
17351 LR2 Set-Error OUT Load restoration element 2 Setting Error
17352 LR2 Monitor OUT Load restoration element 2 monitor mode
17353 LR3 Start OUT Load restoration element 3 Start
17354 LR3 Pickup OUT Load restoration element 3 Pickup
17355 LR3 CB Close OUT Load restoration element 3 CB Close
17357 LR3 Active OUT Load restoration element 3 Active
17358 LR3 Set-Error OUT Load restoration element 3 Setting Error
17359 LR3 Monitor OUT Load restoration element 3 monitor mode
17360 LR4 Start OUT Load restoration element 4 Start
17361 LR4 Pickup OUT Load restoration element 4 Pickup
17362 LR4 CB Close OUT Load restoration element 4 CB Close
Addr. Parameter Setting Options Default Setting Comments
