Siemens SIPROTEC 7RW80 User Manual

Appendix
A.5 Protocol-dependent Functions
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
223
A.5 Protocol-dependent Functions
Protocol → IEC 60870-5-103 IEC 61850 Ether-
net (EN 100)
Profibus DP DNP3.0
Modbus ASCII/RTU
Function ↓
Operational Measured
Values
Yes Yes Yes Yes
Metered Values Yes Yes Yes Yes
Fault Recording Yes Yes No No
Remote Protection Setting No Yes No No
User-defined Indications
and Switching Objects
Yes Yes Yes Yes
Time Synchronization Yes Yes Yes Yes
Messages with Time Stamp Yes Yes Yes Yes
Commissioning Aids
Measured Value Indication
Blocking
Yes Yes No No
Creating Test Messages Yes Yes No No
Physical Mode Asynchronous Synchronous Asynchronous Asynchronous
Transmission Mode cyclically/Event cyclically/Event cyclically cyclically/Event
(DNP)
cyclically
(Modbus)
Baud Rate 1.200 to 115.000 Up to 100 MBaud Up to 1.5 MBaud 2400 to 19200
Type – RS232
– RS485
– Fiber-optic
cables
Ethernet TP – RS485
– Fiber-optic
cables (double
ring)
– RS485
– Fiber-optic cables
