Siemens SIPROTEC 7RW80 User Manual

Technical Data
4.1 General Device Data
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
180
4.1.5 Electrical Tests
Standards
Insulation test
Ethernet electrical (EN 100) for
IEC61850 and DIGSI
Connection Back case bottom, mounting location "B”
2 x RJ45 socket
100BaseT in acc. with IEEE802.3
Test voltage (with regard to the
socket)
500 V; 50 Hz
Transmission Speed 100 Mbit/s
Maximum distance of transmis-
sion
20 m
Ethernet electrical (EN 100) for
IEC61850 and DIGSI
Connection Back case bottom, mounting location "B”
LC connector 100BaseF in acc. with
IEEE802.3
Transmission Speed 100 Mbit/s
Optical wavelength 1300 nm
Maximum distance of transmis-
sion
max. 2 km
Standards: IEC 60255
IEEE Std C37.90, see individual functions
VDE 0435
for more standards see also individual functions
Standards: IEC 60255-27 and IEC 60870-2-1
Voltage test (routine test) of all circuits except auxil-
iary voltage, binary inputs and communication ports
2.5 kV, 50 Hz
Voltage test (routine test) of auxiliary voltage and
binary inputs
DC 3.5 kV
Voltage test (routine test) of isolated communica-
tion ports only (A and B)
500 V, 50 Hz
Impulse voltage test (type test) of all process circuits
(except for communication ports) against the inter-
nal electronics
6 kV (peak value);
1.2/50 µs; 0.5 J;
3 positive and 3 negative impulses at intervals of 1 s
Impulse voltage test (type test) of all process circuits
against each other (except for communication
ports) and against the PE terminal of class III
5 kV (peak value);
1.2/50 µs; 0.5 J;
3 positive and 3 negative impulses at intervals of 1 s
