4.9 User-defined Functions (CFC)
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
200
Configurable in Matrix
Type converter BOOL_TO_DI 5
BUILD_DI 5
DI_TO_BOOL 5
DM_DECODE 8
DINT_TO_REAL 5
DIST_DECODE 8
UINT_TO_REAL 5
REAL_TO_DINT 10
REAL_TO_UINT 10
Comparison COMPARE 12
LOWER_SETPOINT 5
UPPER_SETPOINT 5
LIVE_ZERO 5
ZERO_POINT 5
Metered value COUNTER 6
Time and clock pulse TIMER 5
TIMER_LONG 5
TIMER_SHORT 8
ALARM 21
FLASH 11
Individual Element Number of TICKS
In addition to the defined preassignments, indications and measured values can be freely configured to buff-
ers, preconfigurations can be removed.
