VLAN C ONFIGURATION
2-83
CLI – This example adds Port 3 to VLAN 1 as a tagged port, and
removes Port 3 from VLAN 2.
Configuring VLAN Behavior for Interfaces
You can configure VLAN behavior for specific interfaces, including
the default VLAN identifier (PVID), accepted frame types, ingress
filtering, GVRP status, and GARP timers.
Command Usage
• GVRP – GARP VLAN Registration Protocol defines a way for
switches to exchange VLAN information in order to
automatically register VLAN members on interfaces across the
network.
• GARP – Group Address egistration Protocol is used by GVRP
to register or deregister client attributes for client services
within a bridged LAN. The default values for the GARP timers
are independent of the media access method or data rate.
These values should not be changed unless you are
experiencing difficulties with GVRP registration/deregistration.
Command Attributes
• PVID – VLAN ID assigned to untagged frames received on the
interface. (Default: 1)
- If an interface is not a member of VLAN 1 and you assign its
PVID to this VLAN, the interface will automatically be added
to VLAN 1 as an untagged member. For all other VLANs, an
interface must first be configured as an untagged member
before you can assign its PVID to that group.
Console(config)#interface ethernet 1/3 3-92
Console(config-if)#switchport allowed vlan add 1 tagged 3-138
Console(config-if)#switchport allowed vlan remove 2
b_mgmt.book Page 83 Tuesday, July 8, 2003 5:24 PM

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Specifications

General

Ports	8
Port Type	10/100/1000 Mbps
Switching Capacity	16 Gbps
Forwarding Rate	11.9 Mpps
MAC Address Table Size	8K
Power over Ethernet (PoE)	Yes
Input Voltage	100-240VAC
Form Factor	Desktop/Rackmount
Features	VLAN, QoS, IGMP Snooping
Dimensions	280 x 180 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Jumbo Frame Support	Yes (9K bytes)
