T
ROUBLESHOOTING
A-2
Cannot access
the on-board
configuration
program via a serial
port connection
Be sure to have set the terminal emulator program to
VT100 compatible, 8 data bits, 1 stop bit, no parity
and 9600 bps.
Check that the null-modem serial cable conforms to
the pin-out connections provided in Appendix B.
Forgot or lost the
password
Set the switch to its default configuration. Make a
direct connection to the switch’s console port and
power cycle the switch. Immediately after powering
on, press <Ctrl><u> to access the system file menu.
Select <D> to delete all user-defined configuration
files. Press <Q> to boot the switch.
Troubleshooting Chart
Symptom Action
b_mgmt.book Page 2 Tuesday, July 8, 2003 5:24 PM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart and is the answer not in the manual?

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Specifications

General IconGeneral
Ports8
Port Type10/100/1000 Mbps
Switching Capacity16 Gbps
Forwarding Rate11.9 Mpps
MAC Address Table Size8K
Power over Ethernet (PoE)Yes
Input Voltage100-240VAC
Form FactorDesktop/Rackmount
FeaturesVLAN, QoS, IGMP Snooping
Dimensions280 x 180 x 44 mm
Operating Temperature0°C to 40°C
Storage Temperature-20°C to 70°C
Humidity10% to 90% (non-condensing)
Jumbo Frame SupportYes (9K bytes)
