SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart User Manual

M ANAGING F IRMWARE
2-27
Web – Click System, Firmware. Enter the IP address of the TFTP
server, enter the file name of the software to download, select a
file on the switch to overwrite or specify a new file name, then
click Transfer from Server.
When you download a file using a different name from the current
runtime code file, you need to select the new file name from the
drop-down box for the operation code used at startup, and then
click Apply Changes.
To start the new firmware, reboot the system.
b_mgmt.book Page 27 Tuesday, July 8, 2003 5:24 PM

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Specifications

General

Ports	8
Port Type	10/100/1000 Mbps
Switching Capacity	16 Gbps
Forwarding Rate	11.9 Mpps
MAC Address Table Size	8K
Power over Ethernet (PoE)	Yes
Input Voltage	100-240VAC
Form Factor	Desktop/Rackmount
Features	VLAN, QoS, IGMP Snooping
Dimensions	280 x 180 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Jumbo Frame Support	Yes (9K bytes)
