Sony DSR-200A User Manual

55
Advanced operations
Adjusting the shutter speed
Adjust the shutter speed to control the picture quality. When recording sports events,
for example, use a high speed shutter to record fast moving objects clearly.
You can select from 6 different shutter speeds SLOW, 60, 100, 250, 1000 and USER
PRESET. SLOW and USER PRESET have their own menus. Refer to “To adjust the
SLOW SHTR (shutter) or S (shutter) PRESET menu items”.
Shutter speed numbers that appear in the viewfinder are inverted. For example, “250”
means 1/250 sec.
(1) Set AUTO LOCK to OFF.
(2) Set AUTO/MANUAL under the SHUTTER SPEED dial to MANUAL.
(3) Turn SHUTTER SPEED to select a shutter speed. Using the dial, you can select
SLOW, 60, 100, 250, 1000, or USER PRESET. The shutter speed indicator
appears in the viewfinder screen.
To return to automatic shutter speed mode
Set AUTO/MANUAL below the SHUTTER SPEED dial to AUTO.
1
2
3
ON OFF
AUTO LOCK
SHUTTER SPEED
SLOW USER
PRESET
60
100 250
1000
AUTO
MANUAL

Sony DSR-200A Specifications

Lens

zoom	10 x Zoom (f = 5.9 to 59 mm)
digital zoom	20 x
filter diameter	52 mm

Camera

image device	3 CCD 1/3-inch, Interline-Transfer Sensor
picture elements	768 (h) x 494 (v) (effective), 811 (h) x 508 (v) (total)
signal system	EIA standard, NTSC Color system

Power

power requirement	DC 7.2 V (Battery operation), DC 8.4 V (AC adaptor)
power consumption	11.6 W (during camera recording)
external DC input	4-pin for DK-715 cable

Operating Environment

operating temperature	0 C˚ to 40 C˚ (32 F˚ to 104 F˚)
storage temperature	-20 C˚ to 60 C˚ (-4 F˚ to 140 F˚)
viewfinder interface	8-pin connector

Dimensions

width	216 mm
height	237 mm
depth	474 mm

Weight and Dimensions

mass without tape and batteries	3.6 kg
mass with tape and batteries	4.7 kg
dimensions (w x h x d)	216 x 237 x 474 mm
