Sony DSR-200A User Manual

Index
A, B
Adjusting viewfinder ............. 27
AE SHIFT ................................. 69
AUDIO MODE........................ 29
AUDIO MONITOR ................ 66
Auto focus............................... 52
AUTO LOCK ........................... 49
BEEP ........................................ 28
BUILT-IN MIC ........................ 67
C, D
Camera recording .................. 26
Charging battery .................... 21
Cleaning video heads ............ 86
Clock set .................................. 80
Connection.............................. 34
Custom preset ........................ 69
DATA CODE .......................... 73
Depth of field ......................... 54
Digital zoom ........................... 30
Display window ..................... 16
DISPLAY ................................. 36
DV connecting cable............... 74
E
Editing ..................................... 74
EDITSEARCH ........................ 33
EJECT (6) ............................... 25
F, G, H
Fade-in/Fade-out .................. 43
FADER/OVERLAP ......... 43, 44
Gain .......................................... 58
House current.......................... 38
I, J, K, L
ID............................................... 13
LANC ........................................ 8
Lithium battery ...................... 78
M, N
Manual focus .......................... 51
Menu system .......................... 40
MIC (microphone) jack ......... 28
MIC ........................................... 67
ND filter ................................... 63
O, P
One-push white balance ........ 61
Overlap .................................... 44
Playback pause....................... 37
Power sources ........................ 38
Power zoom ............................ 30
PEAK ....................................... 66
Q, R
Rec review .............................. 33
Recording mode...................... 29
Remote control jack (LANC)
.................................................... 8
Reverse .................................... 37
S
Shoulder strap ........................ 16
Shutter speed .......................... 55
Skip scan ................................. 37
SPEAKER ................................. 28
Standby mode ........................ 28
STEADYSHOT ....................... 68
T, U, V
TC RESET................................... 9
Tripod mounting ................... 17
Trouble check ......................... 90
VTR4 ........................................ 11
W, X, Y, Z
White balance ......................... 60
Zebra pattern ........................... 64
Sony Corporation Printed in Japan

Sony DSR-200A Specifications

Lens

zoom	10 x Zoom (f = 5.9 to 59 mm)
digital zoom	20 x
filter diameter	52 mm

Camera

image device	3 CCD 1/3-inch, Interline-Transfer Sensor
picture elements	768 (h) x 494 (v) (effective), 811 (h) x 508 (v) (total)
signal system	EIA standard, NTSC Color system

Power

power requirement	DC 7.2 V (Battery operation), DC 8.4 V (AC adaptor)
power consumption	11.6 W (during camera recording)
external DC input	4-pin for DK-715 cable

Operating Environment

operating temperature	0 C˚ to 40 C˚ (32 F˚ to 104 F˚)
storage temperature	-20 C˚ to 60 C˚ (-4 F˚ to 140 F˚)
viewfinder interface	8-pin connector

Dimensions

width	216 mm
height	237 mm
depth	474 mm

Weight and Dimensions

mass without tape and batteries	3.6 kg
mass with tape and batteries	4.7 kg
dimensions (w x h x d)	216 x 237 x 474 mm
